RCB12
The REAC Control Box – RCB12 is a compact 4 channel control box ideal for limited spaces in a various range of assistive products.
Introducing RCB12
It can operate almost any actuator or DC-motor. It has customizable current limits, soft start and soft stop, which can be adjusted via REAC Service Tool, RST10.
It is easily operated with REAC Hand Control, RHC10. As an option to the hand control it can also be connected to an RHC12, which provides four digital inputs for those who e.g. prefers common switches instead of the hand control.
It is compatible with REAC Power Pack, RPP10 and prepared for connecting to AC mains power.
Features
| Controls | 1 – 4 channels, individual actuators |
| Current limit control | 8A |
| System power | 24VDC |
| Batteries | Compatible with RPP10 |
| Charger | N/A |
| Protection class | IPX4 |
| Weight | 0.3 kg |
| Operating temperature | -25°C to +50 °C |
| Storage temperature | -40°C to +70 °C |
| Color | Black (RAL 9005) or White (RAL 9016) |
| Soft start/stop | Yes (Customizable via PC-tool – adapter required) |
| Operation interface | RHC10 (or common switches via RHC12) |
| EMC conformity | IEC/EN 61000-6-2 2005 (C1 2005), 61000-6-3 2007, 60601-1-2 2015, 7176-21 2009 |
| Flammability rating | UL94V-0 |
